1301鋼筋彎曲機 Steel bar bender
鋼筋彎曲機結構簡單、工作可靠、操作靈敏，可使6-40/50mm的鋼筋彎成橋梁和其他建筑工程中所需要的各種形狀。
Bar bending machine, another name is Steel bar bender ,it has simple structure, reliable operation, sensitive operation, can make 6-40/50 mm steel be bent into various shapes needed of a bridge and other construction engineering.
性能特點：
采用加厚機架、配置優質配件、加厚面板（10mm），鋼件軸承罩、鋼件圓盤、加厚蝸殼、加厚蝸桿、全鋼實心輪、國標4KW銅線電機、大方支座、加粗送料輥、全鋼精磨附件，本機使用一段時間后應將工作盤換成180度方位使用，這樣內部機件也改變180度位置，使機器零件達到均勻磨損，延長機器使用壽命。
Performance and characteristics:
Adopt more thickening frame, configuration of high quality accessories, panel (10 mm), steel bearing cover, steel disk, thickening volute, thickening worm, all steel solid wheel, GB 4 kw copper wire motor, generous support, bold feed roller, all steel accessories, this machine is used for a period of time ,work plate should be used with 180 degrees of bearing, so that the interior also changed 180 degrees, to achieve uniform wear in machine parts and prolong the service life of the machine.
主要技術參數：
彎曲鋼筋直徑：φ6-φ50mm
彎曲鋼筋直徑：Ⅱ級螺紋鋼
工作圓盤直徑：320-350mm
工作圓盤轉速：5-14r/min
電機功率:3/4kw
電機轉速：1440轉/分
電壓：380V/50HZ
整機質量：280/500kg
The main technical parameters:
Bending rebar diameter: φ6-φ50mm
Rebar bending rebar diameter: Ⅱ level screw-thread steel
Work the disc diameter: 320-350mm
Work disk rotational speed: 5-14 r/min
The motor power: 3/4 kw
Motor speed: 1440 r/min
Voltage: 380V/50HZ
The whole machine quality: 280/500 kg
